12V 7.2Ah Sealed Lead Acid AGM Battery CSB GP1272 F1 Terminal

CSBGP1272

New product

CSB GP1272 F1 Terminal Sealed Lead Acid Battery

5 Year Design Life

12V

7.2Ah

Please contact us for quantity discounts

Email: info@createenergy.co.za or telephone: +(27) 11 888 0410

More details

In Stock, Subject to Prior Sale

R 249.95 tax incl.

More info

CSB GP1272 F1 Terminal Sealed Lead Acid Battery

5 Year Design life in Standby Use

Maintenance Free

12V

7.2 Amp Hours

GP1272
12 V 7.2Ah

GP 1272 is a general purpose battery up to 5 years in standby service or more than 260 cycles at 100% discharge in cycle service.


As with all CSB batteries, all are rechargeable, highly efficient, leak proof and maintenance free.

Specification

Cells Per Unit 6
Voltage Per Unit 12 V
Capacity 7.2 Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F)
Weight (kg) Approx. 2.40kg. (5.29 lbs.)
Maximum Discharge current (A) 100A/130A (5sec.)
Internal Resistance Approx. Approx. 23mΩ
Operating Temperature Range Discharge:-15℃~50℃(5°F~122°F)
Charge:-15℃~40℃(5°F~104°F)
Storage:-15℃~40℃(5°F~104°F)
Nominal Operating Temperature Range 25°C ± 3°C (77°F ± 5°F)
Float charging voltage 13.5 to 13.8 VDC/unit Average at 25°C (77°F)
Recommended Maximum Charging current limit 2.16A
Equalization and Cycle Service 14.4 to 15.0 VDC/unit Average at 25°C (77°F)
Self Discharge It should be more than 75% of the capacity that before storage after stocked for 6 months at ambient temp. 25℃
Terminal F1/F2-Faston Tab187/250
Container Material ABS(UL94-HB) & Flammability resistance of(UL94-V0) can be available upon request.


Constant Current Discharge Characteristics Unit: AMPERES (25°C,77°F)

F.V/Time 5MIN 10MIN 15MIN 30MIN 60MIN 90MIN 2HR 3HR 5HR 8HR 10HR 20HR
1.60V 35.60 22.00 16.50 9.61 5.51 3.92 3.08 2.13 1.34 0.92 0.77 0.45
1.67V 33.10 21.00 15.90 9.36 5.41 3.85 3.02 2.08 1.31 0.90 0.76 0.44
1.70V 31.90 20.50 15.60 9.24 5.37 3.82 3.00 2.06 1.30 0.89 0.75 0.43
1.75V 29.60 19.60 15.10 9.03 5.30 3.77 2.96 2.02 1.27 0.88 0.74 0.42
1.80V 27.20 18.60 14.40 8.77 5.23 3.71 2.91 1.98 1.25 0.87 0.73 0.42
1.85V 24.50 17.40 13.70 8.44 5.14 3.66 2.87 1.95 1.22 0.86 0.71 0.40

Constant Power Discharge Characteristics Unit: WATTS (25°C,77°F)

F.V/Time 5MIN 10MIN 15MIN 30MIN 60MIN 90MIN 2HR 3HR 5HR 8HR 10HR 20HR
1.60V 360.00 245.00 183.00 108.00 64.40 47.10 37.70 26.60 17.30 11.80 9.80 5.37
1.67V 340.00 235.00 177.00 106.00 63.60 46.40 37.10 26.30 17.00 11.60 9.68 5.27
1.70V 331.00 231.00 174.00 105.00 63.10 46.10 36.90 26.20 16.90 11.50 9.54 5.23
1.75V 313.00 222.00 170.00 103.00 62.40 45.50 36.40 25.90 16.70 11.40 9.47 5.15
1.80V 295.00 213.00 165.00 101.00 61.70 45.00 35.90 25.60 16.50 11.30 9.40 5.07
1.85V 276.00 202.00 158.00 99.00 60.80 44.30 35.40 25.20 16.30 11.20 9.29 4.99

Download

CSB GP1272 Spec Sheet

CSB GP1272 Specifications Data Sheet

Download (670.74k)
