Victron Nucleo GX
R4,632.20
R3,103.11
Tax included
The Nucleo GX is a compact communication centre that brings Ekrano GX-class performance to systems that don't need a full set of connections. Fast, responsive and cost-optimised, it is the most focused member of the GX family.
It is the logical choice for two kinds of systems: those built around an RS or HS series inverter/charger, connected via VE.Can, and simpler systems with just one or more solar chargers or a SmartShunt, connected via VE.Direct. Should needs grow, USB accessories add connections the Nucleo GX doesn't have on board. Monitor and control the system from anywhere with the Victron Remote Monitoring (VRM) portal and the VictronConnect app.
Not sure which GX device suits the system? See the GX Communication Centre for full comparison.
Nucleo GX
Nucleo GX: communication-centre
The Nucleo GX is a compact, high-performance communication centre for monitoring and controlling your Victron system. It offers fast system response, reliable connectivity, and flexible expansion via USB accessories. Ideal for VE.Can-based installations such as RS systems, it provides full GX functionality with simple setup and seamless remote access through VRM, LAN, or WiFi. Additional functionality such as VE.Bus connectivity, relays, or analogue inputs can easily be added via optional USB accessories: the MK3-USB interface, GX I/O Extender 150, or GX Tank 140. Although the Nucleo GX has no HDMI port, an Android GX WiFi Display can be used for local display and control. System access is also available through VictronConnect, a web browser, or VRM.
Compact and high-performance GX platform
Equipped with a quad-core processor, the Nucleo GX delivers fast and reliable system performance in a compact design. It supports up to 25 connected devices via VE.Direct and USB, and even more via VE.Can, ensuring smooth data handling and responsive control in any installation.
Remote Console on VRM
Monitor, control, and configure the Nucleo GX remotely, just as if you were standing in front of it, using Remote Console on VRM. The same functionality is available locally via LAN or through the built-in WiFi Access Point.
Perfect monitoring & control
Monitor real-time system information such as battery state of charge, power consumption, and power harvest from PV, generator, or mains. Easily start or stop generators automatically, adjust key system settings, and track performance trends. Stay informed with alerts, run diagnostics, and resolve issues remotely through VRM or the local network.
Simple mounting and configuration
The Nucleo GX is easy to install on a wall or with the optional DIN35 DIN-rail adapter. Built-in Bluetooth enables quick setup and configuration using the VictronConnect app.
