Adventure-X Super Slimline 12.8V 230Ah Lithium Battery Victron VE CANBUS BMS

Adventure-X Super Slimline 12.8V 230Ah Lithium Battery Victron VE (With Victron VE CANBUS BMS)

by Trailersol

The New Slimline range of Adventure-X Lithium Iron Batteries allows for a more portable power solution for your off-road adventures.

Only 80mm in width , this battery is suitable for behind the seat installations and where space is limited

CANBUS BMS COMPATABLE WITH VICTRON GX DEVICE (Colour Control, Cerbo, Ekrano)

Specifications

• Capacity: 230 Ah
• Nominal Voltage: 13.1V
• Maximum Continuous Discharge Current: 230 Amps
• Peak Discharge Current (10 sec): 300 Amps
• Maximum Continuous Charge current: 180 Amps
• Weight: 20 kg
• Short Circuit Protection: Yes
• Over Voltage Protection: Yes
• Under Voltage Protection: Yes
• Over Current Protection: Yes
• Dimensions: 760mm x 240mm x 80mm
• Includes CANBUS Cable.

Performance

• Charge Temperature: 0°C- 65°C
• Discharge Temperature: -10°C- 65°C
• Number of Cycles (100% DOD): 4000
• Warranty: 5 Years

Standard Warranty: 5 Years / 5000 cycles (Whichever comes first) manufacturer's limited carry in warranty (Owing to normal use and installation as per specifications, installation manuals, local laws and regulations)

Depth of discharge: 90%

All Adventure-X Batteries are rated at 1C Discharge Rates - 0.8C Charge Currents

Steel Powder Coated batteries have high current output terminals

All slimline batteries come with Hexsert mounting points
All batteries have bluetooth enabled BMS for monitoring

*Specifications might be subject to change by the manufacturer
