Lowrance HDS PRO 10 AIHD 3-in-1 Transducer Fishfinder Chartplotter Combo
R63,925.00
R54,336.25
Tax included
Lowrance HDS PRO 10 AIHD 3-in-1 Transducer Fishfinder Chartplotter Combo
10 inch SolarMAX HD IPS display, Dual 1kW sonar with CHIRP, ActiveImaging™ HD ready. Networkable to Lowrance performance sonars (ActiveTarget™ and ActiveTarget™2), Radars, Trolling Motors, and Autopilots along with waypoint, chart, and sonar sharing. Worlwide basemap (chart card required).
With AIHD 3-in-1 Transducer
Lowrance HDS PRO 10 AIHD 3-in-1 Transducer Fishfinder Chartplotter Combo
See more and catch more with HDS® PRO, the ultimate fishfinding tool. With built-in support for the new, ultra high-definition Active Imaging™ HD and the new, highest-resolution live sonar ActiveTarget® 2 you’ll see more clearly and find more fish than ever before.
Lowrance HDS-10 PRO, 10 inch SolarMAX HD IPS display, Dual 1kW sonar with CHIRP, ActiveImaging™ HD ready. Networkable to Lowrance performance sonars (ActiveTarget™ and ActiveTarget™2), Radars, Trolling Motors, and Autopilots along with waypoint, chart, and sonar sharing. Worlwide basemap (chart card required).
With AIHD 3-in-1 Transducer
SAVE UP TO ZAR 9500
SEE MORE. CATCH MORE.
Experience the next level of fishfinding with new HDS® PRO displays, featuring the ultimate clarity of enhanced Lowrance sonar, the latest C-MAP® charts and easy bow-to-stern control.
NEW LOWRANCE SONAR
Key Features
SolarMAX™ HD Touchscreen viewable at extreme angles and through polarized lenses
New! High-definition up to 1.2MHz Active Imaging™ HD ready (Lowrance CHIRP/SideScan/DownScan Imaging™)
New! High-resolution ActiveTarget® 2 Live Sonar ready
FishReveal™ with new SideScan view, as well as Downscan*
Available in 9, 10, 12 and 16-inch display size
Preloaded C-MAP® DISCOVER OnBoard charts with 1-foot contours on 19,000+ US Lakes, 9,400+ Canadian Lakes or worldwide basemap
Real-time mapping available with C-MAP® Genesis Live.
Support for new ActiveTarget® Scout and Ghost® Trolling Motor 360 chart overlay views
Large programmable keys for 10, 12 and 16-inch sizes
Touchscreen control of Power-Pole® anchors, Ghost® Trolling Motor, Autopilot and Lowrance Outboard Pilot
NMEA 2000®, Wireless and Bluetooth®, connectivity – plus smartphone notifications
Wide range of optional chart upgrades including C-MAP® REVEAL, Navionics®, Florida Marine Tracks and more.
*SidescanFishReveal requires S3100 module and a compatible transducer
Experience the next level of fishfinding with new HDS® PRO displays, featuring the ultimate clarity of enhanced Lowrance sonar, the latest C-MAP® charts and easy bow-to-stern control.
ACTIVE IMAGING™ HD
Our clearest sonar ever, Active Imaging™ HD delivers high-definition views of Lowrance CHIRP sonar, SideScan and DownScan Imaging™.
FISHREVEAL™
FishReveal™ has also been expanded to be available on SideScan* and DownScan, making fish easier to identify to the sides and beneath the boat.
*SideScan with FishReveal™ requires AI 3-in-1 HD Transducer Plus S3100 module
ACTIVETARGET® 2 LIVE SONAR
ActiveTarget® 2 Live Sonar provides higher-resolution views of fish movement and structure.
ADDITIONAL LIVE SONAR VIEWS
HDS® PRO also supports plug-and-play installation of two ActiveTarget® systems, making it possible to watch multiple views simultaneously, and to widen Front and Scout modes for better bait tracking.
NEW CHART OVERLAY
HDS® PRO also introduces a new chart overlay option, allowing you to view ActiveTarget® Scout Mode or Ghost® 360 trolling motor mode directly on the chart screen.
THIRD-PARTY COMPATIBILITY
For anglers that want to select their own chart, HDS® PRO supports a wide range of third-party chart options, including C-MAP®, Navionics®, Florida Marine Tracks and more.
BUILT-IN SUPPORT
HDS® PRO offers support for the complete range of top fish-finding technologies – from ActiveTarget® 2 Live Sonar and Active Imaging™ HD to touchscreen control of Ghost® Trolling Motor, Power-Pole® Anchors and more.
CONNECTIVITY
Expand your system -- taking advantage of radar, autopilot and NMEA 2000® compatibility -- and add SiriusXM® Weather/Audio to monitor changing weather conditions and to listen to your favorite tunes.
PLUG 'N PLAY
Beyond the 9, 10, 12 and 16-inch screen sizes, HDS® PRO can also be expanded to deliver additional views and features. With plug-and-play installation, expanding your fishing has never been easier.
FishReveal™ SideScan
Simply add an S3100 sonar module and compatible Active Imaging™ HD transducer to enable the new FishReveal™ SideScan view, making it easier to identify fish to the sides of the boat.
SCOUT WIDE VIEW
ULTIMATE CLARITY
Multiple live sonar views
Anglers can also add a second ActiveTarget® system to better target fish by viewing multiple ActiveTarget® 2 Live Sonar displays at the same time.
TOGETHER IN BOX
- LOWRANCE AIHD 3-in-1 Transducer
- LOWRANCE PC-30 POWER / DATA CABLE & FUSE
- HDS-10 LIVE/PRO Bracket and Knobs
- HDS-9 LIVE/PRO Suncover
SPECIFICATIONS
SKU 10-02-232
Display
| Backlight Color | Pure White LED |
| Display Resolution | 1280 x 800 |
| Screen Brightness | >1200 Nits |
| Viewing Angles | 80° top/bottom, 80° left/right |
Electrical
| Power Consumption max | 2.9A @ 13VDC with Full Backlight, Sonar on |
| Power Consumption min | 2.0A @ 13VDC with Full Backlight, Sonar on |
| Power Consumption typical | 2.0A @ 13VDC with Full Backlight, Sonar on |
| Recommended Fuse Rating | 3 A |
| Supply Voltage | 12 v DC (10.8-17 V DC) |
Physical
| Dimensions | W x H x D 11.06in (294.6 mm) x 7.6in (193.15 mm) x 3.3 in (82.5 mm) |
| Weight | 3.66lb (1.66kg) |
| Compass Safe | 1.6 ft (50 cm) |
| Mounting Type | Panel mount or bracket mount |
Environment
| Humidity | 60°C, 95% relative humidity (RH) for 18 hours |
| Operating Temperature Range | 5°F to 131°F (-15°C to 55°C ) |
| Shock Vibration | 100,000 cycles of 20 G |
| Storage Temperature Range | 4°F to 140°F (-20°C to 60°C ) |
| Waterproof rating | IPX7 with card door closed |
Interface
| Touchscreen | Full Multi-touch touchscreen |
| Keypad | 8-way directional keypad |
| User programable keys | 2 |
| Buttons | Zoom +/-, Exit, Enter, Menu, Waypoint, Power / Light |
Connectivity
Bluetooth® 5.2 with support for Bluetooth® classic
| Ethernet Ports | 2 x 100 Mbit, 6 max MFD’s on a network |
| Connectivity Wi Fi | Internal 802.11b/g/n and Compatible with WiFi-1 Module |
| NMEA 2000 | 1x Micro-C |
| SD Card Storage | 2 micro SD cards up to 32GB FAT32, Larger if formatted NTFS |
| NMEA 0183 | via Power cable |
Video
| Output | None |
| Input | Composite video RCA – single channel via optional adaptor cable |
GPS
| Correction | DGPS, WAAS |
| GPS Receiver Channels | 16 |
| Position Accuracy | 20m RMS |
| Time to First Fix | 30s |
| Update rate | 10 Hz |
MFD
| Sonar Compatibility | Integrated: Dual channel CHIRP Broadband, ActiveTarget (2), ActiveImaging (HD) DownScan, ActiveImaging (HD) SideScan. Compatible with: S3100, StructureScan, StructureScan3D, S5100, SonarHub |
| Radar | All HALO Radars |
| Weather | SiriusXM via WM-4 (USA only) |
| AIS | AIS Chart and Radar overlay. Target vessel details. |
| Autopilot | NAC-1, NAC-2, NAC3, Outboard Pilot, MotorGuide Xi5/Xi3 Trolling Motor **requires Motorguide PinPoint Gateway |
| Digital Switching | CZone, Naviop, DDS |
| GPS | 10 Hz GPS/GLONASS WAAS/EGNOS/MSAS |
| Internal Storage | 8.0 GB Internal |
| Multimedia | SonicHub, SonicHub 2, FusionLink products, any NMEA 2000 compliant Marine Audio products |
| Sonar Output Power | 1kW |
| Waypoints, Routes, Tracks | 3000 Waypoints, 100 Routes, 100 Trails with up to 10,000 points per trail |
| HTML5 | Support for third part HTML apps |
| Autopilot Maneuvers Turn Patterns | Course, Heading, Waypoint, Power Steer, U-Turn, C-Turn, Spiral, Zigzag, Square, Lazy-S |
| Steering Modes | Course, Heading, Waypoint, Power Steer |
Transmit and Receive:
NMEA 0183 Sentences supported
| GPS Receive | GGA GLL GSA GSV VTG ZDA Transmit GGA GLL GSA GSV VTG ZDA GLCTX / RX |
| Navigation Receive | RMCTransmit AAM APB BOD BWC BWR RMC RMB XTE XDRTX / RX |
| Sonar Receive | DBT DPT MTW VLW VHM, Transmit DBT DPT MTW VLW VHMTX / RX |
| Compass Receive | HDG HDT HDM, Transmit HDGTX / RX |
| Wind Receive | MWV MWD, Transmit MWV MWDTX / RX |
| AIS / DSCReceive | DSC DSE VDM |
Approvals
| Approvals Compliance | FCC, Industry Canada, Radio Equipment Directive, ACMA, RSM |
ActiveImaging HD™ 3-in-1 Transducer
SKU: 000-16062-001
Step up to the ultimate fishfinding clarity with new, high-definition Active Imaging™ HD 3-in-1 sonar. Get the clearest images of fish and structure from Lowrance® CHIRP sonar, high-frequency (up to 1.2MHz) SideScan and DownScan Imaging™, plus a FishReveal™ DownScan view that makes fish easier to identify below the boat
Key Features
High definition (up to 1.2MHz) SideScan and DownScan Imaging™ deliver the clearest images of fish and structure
Lowrance® CHIRP with superb clarity and target separation
FishReveal™ DownScan view makes fish identification easy
Supports Medium and High CHIRP (83/200kHz) en 455/700/1000/1200 KHz frequencies
Smart transducer design boosts signal clarity
Compatible directly with Lowrance HDS PRO or with a S3100 module with HDS LIVE, HDS Carbon and Elite FS
Specifications
Environment: Humidity60°C, 95% relative humidity (RH) for 18 hours
Operating Temperature Range: 5°F to 131°F (-15°C to 55°C )
Shock Vibration: 100,000 cycles of 20 G
Storage Temperature Range: -22°F to 158°F (-30°C to 70°C )
Waterproofrating: P67
Mounting Type: Transducer Bracket Mount
WeightTransducer: 2.67 lbs (1.21 kg)
Other
Interface: Direct Connect to HDS Pro (Requires S3100 Module for Down Scan Fish Reveal)
Via S3100 Module and Ethernet to: *HDS Live *Elite FS *
Warranty Period: 1 Year
